| Model | EG204AKSZ | EG204AKSZ01 | EG204AKSZ02 | EG204AKSZ03 |
| System | 48V/5KW AC | 48V/4KW Sepex | 48V/4KW Sepex | 48V/5KW AC |
| Key Components | ||||
| Battery | 6PCSxT875(145Ah@5hr rate) | 6PCSxT875(145Ah@5hr rate) | 8PCSxT105(185Ah@5hr rate) | 8PCSxT105(185Ah@5hr rate) |
| Motor | 5KW AC motor | 3.8KW Chinese motor | 3.8KW Chinese motor | 5KW AC motor |
| Controller | Zapi ACE2 (400A@2minutes) | Curtis 1268 (400A@2minutes) | Curtis 1268 (400A@2minutes) | Zapi ACE2 (400A@2minutes) |
| Performance | ||||
| Passenger capacity | 6 | 6 | 6 | 6 |
| Range (loaded) based on flat road at aspeed of 30km/h (km)* | >45 | >40 | >70 | >80 |
| Max.Speed @12.76:1 gear ratio | 32 | 32 | 32 | 32 |
| Max.Speed @10.26:1 gear ratio | - | 40 | 40 | - |
| Minimum turning radius (m) | 4.5 | 4.5 | 4.5 | 4.5 |
| Max.Climbing ability (loaded)@ 12.76:1 gear ratio | 20% | 20% | 20% | 20% |
| Max.Climbing ability (loaded)@ 10.26:1 gear ratio | - | 15% | 15% | - |
| Max.Movement after brake at speed of 20km/h | ≤4m | ≤4m | ≤4m | ≤4m |
| Max.Loading weight | 450kgs | 450kgs | 450kgs | 450kgs |
| Net weight | 600kgs | 590kgs | 640kgs | 650kgs |
| Dimensions | ||||
| Overall dimensions (mm) | 3670*1180*1980 | |||
| Min.Ground clearance (mm) | 120 | |||
| Wheelbase (mm) | 2430 | |||
| Front wheel tread (mm) | 960 | |||
| Rear wheel tread (mm) | 980 | |||
