Hot Sale 1.5t Manual Plainted/Geared Trolley for Chain Block and Electric Chain Hoist

CE standard 1.5t manual trolley for chain block

Details:
Left one is especially exported to North America.
Capacity: From 1T to 10T
Surface treatment: High quality black painted
Standard chain length: 3m, other length available upon request.

Catalog:

Geared Trolley

Model		GCL1	GCL2	GCL3	GCL5	GCL10
Capacity	(kg)	1000kg	2000kg	3000kg	5000kg	10000kg
Test load	(kg)	1500kg	3000kg	4500kg	7500kg	15000kg
Grider width	(mm)	64-203	88-203	100-203	114-203	125-204
Hand Chain size	(mm)	4.8*25
Net weight	(kg)	11.9	16.3	25.7	37.9	62
Gross weight	(kg)	12.3	16.8	26.3	41	72

Plain Trolley

Model		GCT1	GCT2	GCT3	GCT5	GCT10
Capacity	(kg)	1000kg	2000kg	3000kg	5000kg	10000kg
Test load	(kg)	1500kg	3000kg	4500kg	7500kg	15000kg
Grider width	(mm)	64-203	8-203	100-203	114-203	125-204
Net weight	(kg)	8.2	12.6	21.9	34.2	60.7
Gross weight	(kg)	8.6	13.1	22.5	37.3	70.7

Application:

GCL series CE standard manual geared trolley is one of the most popular hoist spare parts, with collision avoidance fucntion, the geared trolley operates by the means of hand chain, which can move smoothly on the bottom of joint steel. The gap between wheels can be also adjusted as the requirements. When being hanged the chain block at the bottom, they can work as the manual lifting and transporting system.

GCT series CE standard manual plain trolley is used in the environment where the entire height is limited. Matching with low headroom hoists it can solve more heavy duty lifting and transporting tasks. Black painted and durable.

Widely used in factory, mine, wharf, warehouse, construction site, etc. Also can used in installing machinery equipment situation and places without electricity.

Feature:

Main advantages: Simple struction, thicken shell, anti-drop.

Housing: 08 type aluminum cold plate

Hand chain: 235 type chain with 4.8mm diameter, wear resistance

Inner part: high grade sealed ball bearing

Painting: matt painted treatment

Shell detail: curling side design, hand chain safeguard

Pulley detail: compact struction, adjustable to any beam width, simply by adjusting the number of collars



Package:

Standard strong carton used for export
