Item | Description |
| Controller | Curtis controller, 275A-400A, imported from USA directly |
| Motor | Rated power 4KW-5KW (5.4HP-6.8HP), Chinese brand or ADC brand |
Battery | Trojan battery, T105+, imported from USA directly |
| Charger | High frequency onboard charger (input 90V-265V, 47-63HZ, output 48V/22A) |
Item | Description |
| Passenger Capacity | 4 |
Range (loaded) (km)* | Up to 65 |
| Max.Speed (km/h) | Up to 40 |
| Min.Turning radius (m) | 4 |
| Max.Climbing ability(loaded) | Up to 20% |
| Max.Movement after brake at speed of 20km/h | ≤4m |
| Max.Loading weight (kgs) | 320 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
Item | Description |
| Overall dimensions (mm) | 3060x1400x1900 (LxWxH) |
| Min.Ground clearance (mm) | 155 |
| Wheelbase (mm) | 2080 |
| Front wheel tread (mm) | 1210 |
| Rear wheel tread (mm) | 1160 |
Item | Description |
| frame &Chassis | Welded steel framework with sand blasting and painting |
| Body | FRP and Plastic |
| Roof | FRP with steel frame, with roof handle |
| Windshield | Laminated glass with wiper |
| Hard door | Aluminum, with lock |
| Seat | Reborn sponge with artificial leather, high back |
| Rear storage box | Steel, with lock |
| Floor | Bamboo floor with Skidproof leather |
| Dashboard | FRP, with F/R switch, emergency light switch, digital meter, combination switch, storage box (2), etc.. |
| Side rear view mirror | 2pcs |
Item | Description |
| Lights | 12V, headlight, front turning light, taillight (brake light and rear turing light) |
Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | Including switch for headlight, turning light, wiper and horn |
| DC/DC converter | 48V/12V |
Digital Meter | With Current meter, voltometer, speedometer, odometer and various indicators |
| Audio system | Radio with MP3 receiver and 2waterproof speaker |
Item | Description |
| Steering System | Single-stage rack and pinion steering system, With automatic compensation function |
Brake System | 4-wheel hydraulic drum brake with hand park brake |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Independent suspension |
| Rear suspension | Integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Integrated, Aluminum differential case, 12.76:1 gear ratio |
| Wheel &Tyre | 225/55b12 6PR tire, 12X7 aluminum wheel |
Item | Option description | Item | Option description |
| 1 | Inner rear view mirror | 5 | CD player |
| 2 | Battery watering pipe | 6 | Wired mircophone |
| 3 | Water pump (handle) | 7 | Solar panel (built in) |
| 4 | Rain cover | 8 | 3-point seatbelt |
