Product Des
cription
| General Description |
| 1 | Driving type | 4*2,left hand drive |
| 2 | Overall Dimension | 4850*2000*2735(mm) |
| 3 | Gross Vehicle Weight | 3750(Kg) |
| 4 | Kerb weight | 2390(Kg) |
| 5 | Rated Payload | 1165(Kg) |
| 6 | Wheel base | 2800(mm) |
| 7 | Fuel type | diesel |
| 8 | Tire Nos | 4 |
| 9 | Tire Specs | 215/75R16LT |
| 10 | Passengers | 3 |
| 11 | Gearbox | Six speed lever,5 speed forward with 1reverse,manual |
| Engine Description |
| 1 | Brand | IVECO |
| 2 | Model | SOFIM8140.43S5 |
| 3 | Displacement | 2798mL |
| 4 | Emission Standard | EURO 5 |
| 5 | Rated Power | 95kw/130hp |
| 6 | Maximum Speed | 100km/h |
| Unit model | L-Z7 |
| Refrigerator Type | Hanxue |
| Applicable temperature (ºC) | -18 |
| Applicable volume(m3) | 2-6 |
| Cooling capacity(W) | Environmental
temperature | 0ºC | 700 |
| -18ºC | 400 |
| Voltage (V) | 12VDC |
| Current (A) | - |
| compssor | Displacement (cc/r) | 87 |
| Remark | Optional to install for 380v store electric power |
advantages of Insulated/Freezer Van Body
1. It is made of GRP and PU foam with all-closed structure that the GRP (Glass Reinforced Plastic Fiber) outside and PU foam in the core.
2. Light in weight: 40% lighter than me
tal body.
3. Non-corrosion, non-pollution, anti-brine, acid and soda-resisting.
4. The panel used for the truck body was co
nstructed in type of sandwich. The thermal insulation layer is 50-80mm thick, which offers avery good thermal insulation performance.
5. Length of Cargo body: 10-40 inch; Capacity of Cargo body: 5-70CBM. The material of the cargo body is optio
nal according to which kinds of goods the truck transport, with perfect heat pservation, box open model: Rear double-open or Side-open.
6. Refrigeration unit Brand Optioanl: American CARRIER, THERMO KING. South Korea hanya. China Songhan, hanxue, etc. The Temperature range can be 0° C~ -20° C. The refrigeration units that we select have simple structure, co
nvenient operation, reliable working, low energy consumption, large refrigerating capacity, small noise, easy installation and maintenance and other advantages.
Other Products
Packing and Delivery
Our Company
Hubei Chengli Groupis located in Chengli auto industry park, Pingyuan town, southern suburb of Suizhou, Hubei. Suizhou is known as Shennong's native land, chime's hometown and "China's Special Vehicle Capital".
It is also the manufacturer of domestic well-known special vehicles used in landscape, petrochemical industry, the municipal enviro
nmental sanitation, and pssure vessel.
The registered trademark of which is "Chengliwei", and the product code is "CLW". It's the im
portant partner of Do
ngfeng and Jiefang. And mainly engaged in manufacturing all kinds of special vehicles and selling full vehicle and fittings to large-scale manufacturers.
The company is ahightech enterprise in hubei province and has passed the certification ofISO9001,ISO16949,GJB9001andCCCauthentication of automobile products.
Advantages of our products1.Our company ChengLi Special Automobile Co.,LTD has manufactured special truck for decades.
2.Our company possesses some advanced technologies and mature craftworks.
3.The truck producedby us has high quality and low price.
4.Ourtrucks are equiped with high quality and efficient equipments.
5.Our trucks are completely produced according to your demands and needs, they are special, professio
nal and uniquefor you.
Our Partners
FAQ
1.You are factory or trading Company?
We are overseas sales department of Chengli automobile and you are always welcomed to visit our factory.
2.Could your company modify the standard product depends on my request?
Yes. Our company is specialized in researching and designing various of special purpose vehicle and spare parts. We can provide any product according to your demand.
3.Could your company totally customize products for me?
We can provide the customized-designing product meeting with any of your demand.
4.Could you provide certification that we need?
We can provide various certifications associated with trailer and truck. Such as DOT, ADR, SASO and so on.
5.How long could we receive our goods?
It depends on the product that you have ordered. If the goods are ppared, we will deliver your goods as soon as possible.Usually it takes 30~45 days to produce them.
6.How a
bout the after-sale service?
We can provide you the technical support to guide you repaire your product. And we will also send original spare parts free of charge by air. If you have special need, we can let our engineer to help you in person.Remember the guarantee period isone year or 12 months.
