| Product Name:drinking water treatment machine with price|
|Water Yield||72 Ton per day|
|Input Water||Sea water, salt water, bore hole well water, river water, bay water, dam water etc|
|Output Water||Fresh water, city tap water water, drinking directly water, bottled mineral water, agriculture use|
|Output Water Saltness||<700mg/L|
|Voltage||110V~450V, 50Hz,60Hz optional|
|Inlet Water Temp||0~40°C|
|Dimension(mm)L*W*H||20 feet container|
|Main Material||Stainless Steel 304/ 316L, RO Membrane etc|
|Application||Yacht,fishing vessel,boat, home/ household use etc.|
With world leading "Reverse Osmosis Membrane technology", the improved design WY-SW-72 seawater desalination equipment efficiently co
nvert seawater into ultra clean and clear drinking water free from odors and bacteria. The co
nverted water meets the natio
nal drinking water quality standard (GB5749-2006).
1) The most advanced RO system and membrane component.
2) Efficient energy recovery technology.
3) Adoption of high-quality safety pssure relief device & observation system.
4) Stable operation & high-quality producing water.
2. Process Flow Diagram
1. Feed pump:equipped with a stainless steel pump, to provide sufficient pssure for subsequent filtration
2. Multimedia filter(Quartz sand filter):mainly remove the mud, suspended solids and large particals in the tap water
3.Activated carbon filter:usually rated by the size of the particles they are able to remove, measured in microns, and generally range from 50 microns (least effective) down to 0.5 microns (most effective).
4. Fine filter:further filtration, protection of reverse osmosis membrane
5. High pssure pump:provide enough pssure for reverse osmosis system
6: Reverse osmosis unit:the core part of pure water equipment, the production of high-purify water
7. Rinse tank:protect the membrane system without polluted by using chemical agent
8. Booster pump:equipped with a stainless steel pump, to provide sufficient pssure for subsequent filtration
9. Active Carbon filter:mainly remove organic substance , residual chlorine and odor in tap water
1) Company Info
Founded in 2010,Zhuhai Wangyang Water Treatment Equipment Co,.Ltd. is a high-tech enterprise integrated with R&D, production, selling and engineering installation. Specializing in seawater desalination, brackish water desalination, reclaimed-water recycling, hyper pure water, boiler-feeding water, electroplating me
tallurgy, we have professio
nal technical team and after-sales team. With co
ntinuous innovation and good quality guarantee, we have abtained some certificate like ISO9001, CCS, etc. As well, we have our own patent.
We persist in the principle "Customers come first, High-quality service, Excellent product". Integrity is the root of our long-term development while customers' satisfaction is our persistent pursuit.
Packaging:International standard export package.
Shipping:15 working days after receiving 30% deposit of total amount of contract or irrevocable L/C at sight.
4. Choose Our Technical Advantages
1) Choose Our Technical Advantages
* The company has obtained ISO9001 quality management system certificate, Inspection certificate of China classification Society(CCS) and the letter of paten for seawater desalination equipment in container.
* We are the direct manufacturer. We have our own factory so that we can offer you high quality product with a good price.
* Owning a self brand "WANGYANG" and a professional practical engineer team.
* Total water solution is available.
* The punctual delivery of goods, quality and quantity guaranteed.
* 8 years experinece, OEM&ODM available.
2)Reverse Osmosis Technology
Reverse osmosis technology is a moderm high technology that use reverse osmosis to seperate water from solution after it permeates the specially-made semi-transparent membrane though exerting a pssure that is higher than the osmosis pssure on the solution.
Reserve osmosis / RO water treatment equipment is mainly used in electronic industry, semiconductor industry water treatment, chemical industry, pharmaceutical industry pure water treatment and so on.
RO system is widely used in school, hotel, hospital, laboratory and many other public area.
5. Our Services
Installation and commissioning
After the equipment arrived buyer's, workshop, the buyer should take it's place for each equipment according to the supplied layout. The seller will send the experienced technician to guide the installation and debugging and trail, production, and fulfill the designed capability within the designed time. The installation, debugging and training is about 7 days.
The seller will supply technical training to the buyer. The training is includes: equipment structure and maintenance, control and operation. After training, the technicians of the buyer will grasp relevant operation and maintenance skills, and could adjust the technologies more skilled, and can deal with all kinds of malfunction in time.
1. After qualified of the equipment, the seller will supply two year guarantee, control system two year guarantee, free charge for wearing parts, and other spare parts with cost price.
2. Within guarantee period, the technicians who accepted training should strictly obey the requirements asked by the seller to operate the equipment and maintenance, to find the common malfunctions and fault clearing in time.
3. If the technicians of the buyer couldn't solve the problems themselves, the after-sales department will supply long range guide service by phone.
4. If relevant measurements couldn't solve the problems, the seller will send the technicians to the buyer factory, clear the fault or relevant technical problems on site, the charges will reference to the installation and debugging charges.
5. After guaranteed, the seller will supply widely favorable technical support, after-sales service for the lifetime: favorable price for the wearing parts and other spare parts.
Q1. Are you a factory or trading company?
Yes, we are a manufacturer with designing, manufacturing, marketing and exporting.
A. We have sophisticated experience and professional knowledge & technology.
B. Both OEM and ODM orders are available.
Q2. Where is your factory located? How can I visit there?
Our factory is located in No.8, Keji Road 1, Tangjiawan, Xiangzhou district, Zhuhai City, Guangdong, China. All our clients, from home or abroad, are warmly welcome to visit us! We are expecting to establish long-term business relations with you and your company.
Q3. What kinds of water treatment equipment do your company offer?
We are specialized in designing and manufacturing the products as follow:
A.Seawater Desalination G.Reclaimed - Water Recycling
B.Brackish Water Desalination H. Ion- Exchange Plant
C. Pure Water Device I. Water Softening Plant
D.Medical Hyper Pure Water J. Sewage Treatment Plant
F. Ultra Filtration Device K. Zero-Discharged Water Treatment Plant
Q4. How are your packing of products?
Usually are bubble bag and wooden box with pallet. But we can pack according to customers' requirement.
Q5. How should I choose the equipment?
It depends on your raw water quality, requirements for permeate water and the water yield.
