1. The HOWO A7 series fromSINOTRUK offers you great value for your money.
It comes without all the fancy items that only look impssive on the specification sheet, but aren't really needed in your daily operation. What you get is thought through and proven quality components that make these 6 x 4 dump truck reliable and easy to drive. Developed with the driver's comfort and safety in mind, you get exactly what you need: just a great truck. Simple and reliable.
1.1 Better aerodynamics with improved front
Improved aerodynamics : better fuel economy, which again improves your bottom line. Easy access for maintenance.
1.2 Ergonomically designed workspace
Ergonomically designed driver's seat: easy reach and access. Comfort for the operator. Design and layout of dashboard provides crucial information in view and all functions in easy reach.
1.3 A comfortable ride with air suspended seats
Air-suspended driver and passenger seats: relaxed and comfortable ride. Seats are fully adjustable, fitting the driver's body.
| 20CBM HOWO A7 6x4 DUMP TRUCK | |||
| Cab | Driving type | Left hand drive(RHD optional) | |
| Type | A7-W low floor, long flat roof cab with one sleeper bed, with A/C | ||
| Engine | Model | D10.38 | |
| Max. output | 276KW/2000rpm(375hp) | ||
| Max torque | 1590Nm/1200-1500rpm | ||
| Displacement | 9.726 L | ||
| Type | 6-cylinder in-line, supercharging & inter cooling, mid turbocharger, high pssure common rail electronic control | ||
| Clutch | Φ430 diaphragm spring clutch, hydraulic control air power assisted . Standard 430B for D10.34 | ||
| Transmission | HW19710,10 speed transmission | ||
| Front axle | HF9 dish type, 9tons | ||
| Driving axle | AC16 reinforced double reduction axles Ratio=4.77 | ||
| Steering | ZF8098 | ||
| Brakes | Service brake : dual-circuit pneumatic brake ; Parking brake : energy storage spring cutoff brake ; Auxiliary brake : engine exhaust brake; EVB,ABS and automatic slack adjuster optional | ||
| Electrics | Voltage : 24V ; Generator : 1540W ; Starter :24V,7.5KW ; Battery : 12V/165Ah , 2 pieces | ||
| Wheel & tires | 12.00R20,10+1spare | ||
| Fuel tank | 300 L | ||
| Weight in kg | Curb weight | 12270 | |
| Gross vehicle weight | 25000 | ||
| Rated payload | 12600 | ||
| Dimension in mm | Overall dimension | 8265 X 2496 X 3490 | |
| Wheel base | 3625+1350 | ||
| Front/rear overhang | 1540/1750 | ||
| Front/rear wheel track | 2041/1830 | ||
| Approach/departure angle | 20 / 26(°) | ||
| Performance | Max. speed | 78 km/h | |
| Min. ground clearance | 314mm | ||
| Dump body | Dump body size(mm) | 5800 X 2300 X1500 | |
| Capacity | 20 CBM | ||
| Thickness of dump body(mm) | floor 8mm,side and back 6mm | ||
| Lifting type | Front type lifting with HYVA cylinder | ||
5. Packing:Nude packing after painting waxoraccordingtoyourrequirement.
Shipping:By bulk cargo carrier, RORO
6. FAQ| Q1: I want the front two tires are bias tires and the rear 9 tires are radial tires, is it ok ? |
| A: We can make the tires as your requirement to suit your country's need. |
| Q2: What about your products quality ? |
| A: Quality is our culture! "Our factory has advanced production technology and management team! We always attach great importance to quality controlling from the very beginning! |
| Q 3: Can i have samples of this type of flatbed semi trailer to test the quality ? |
| A: Yes, you can buy any samples to test the quality,our MOQ is 1 unit. |
| Q 4: What others we can do ? |
| A: According to your order, we will provide the best price and quality trucks and trailers. And we are well capable in offering overseas after-sales service. Besides, we also provide rational packing and shipping program,let shipment save money and security. |
| Q 5: How to guarantee customers get the goods smoothly after they pay ? |
| A: Don't worry, dear. We have been in this field for 10 years, we will send you production photos once in a while, and we will help you to book the latest ship. |
| Q 6: What's the delivery time ? |
| A: The delivery time is within 15 working days after receiving your advance payment. |
| Q 7: Can you supply some quick-wear truck or semi trailer parts ? |
| A: Yes, we can supply truck and semi trailer parts as your request,such as oil filter, fuel filter, air filter, traction, traction pin, balancebeam andsemi-trailer plate spring, hanging accessories, turntable, all kinds of trailer brake pads,brake pan, bearings etc. |
| Q 8: Do you have any used truck and semi trailer for sale ? |
| A: We have some trucks and trailers in stock for choice, from 2010-2016 year, the price are favorable. We'll showyou our stock if you need. |
| Q 9:Which INCOTERMS 2010 TERMS can we work ? |
| MAOWO is a professional and sophisticated international player, can handle all INCOTERMS 2010terms, and we normally work on FOB, CFR, CIF, CIP, EXW. |
| Q 10:What logistics ways we can work for shipment? |
| A: We can ship construction machinery by various transportation tools. (1) For 80% of our shipment, we will go by sea, to all main continents such as South America, Middle East, Africa, Oceania etc. Either by container or RoRo/Bulk shipment. (2) For neighborhood countries of China, such as Russia, Mongolia, Kazakhstan, Uzbekistan , Vietnam, Laosetc.,wecan ship construction machinery by road or railway. (3) For light spare parts in urgent demand, we can ship it by international courier service, such as DHL,TNT, UPS, or Fedex. |
