Place of Origin: | Shandong, China (Mainland) | Brand Name: | HOWO | Model Number: | Sinotruk HOWO 336HP 8m3 6x4 Concrete Mixer Truck Euro II |
Gross Vehicle Weight: | 25000 | Curb Weight (Kg): | 8830 | Total Vehicle Weight (Kg): | 25000 |
Outline Dimension(L*B*H) (mm): | 8204*2496*3850 | Wheelbase (mm): | 3825+1350 |
Packaging Details: | nude packing |
| Delivery Detail: | 35 days |
Model:ZZ1257N3247C | 7m3concretemixertruck | |
WholeVehicle Performance& Parameters | Chassis | HOWO |
CurbWeight(Kg) | 8830 | |
TotalVehicleWeight(Kg) | 25000 | |
OutlineDimension(L*B*H)(mm) | 8204*2496*3850 | |
Wheelbase(mm) | 3825+1350 | |
FrontOverhang(mm) | 1500 | |
RearOverhang(mm) | 1400 | |
Min.ClearanceAboveGround(mm) | 314 | |
Max.TravelingSpeed(km/h) | 90/102 | |
Min.TurningDiameter(M) | <=19 | |
OilConsumptionper100km (underlimitedconditions) | ≤34 | |
Frontaxle | HF99Tplatebrake | |
Rearaxle | HC1616T16toncapacity | |
VehicleConfiguration | Clutch | DrySingleDiscClutch(φ430) |
GearBox | HW15710 | |
DrivingType | 6*4 | |
SteeringMechanism | ZF8098 | |
ServiceBrake | Dual-circuitAirBrake | |
ParkingBraking | Spring-poweredAir-cut-offBrake | |
AuxiliaryBrake | EngineExhaustBrake | |
Tyre | 12.00-20 | |
EngineParameters | Model | WD615 |
Type | In-line6-cylinder,Water-cooled,Supercharged, Inter-cooled,Electric(Direct) InjectionDieselEngine | |
EmissionStandard | EuroII | |
Displacement | 9.726(L) | |
MaxPower(KW) | 247KW336HP(2200rpm) | |
MaxTorque | 1350N.m | |
Maxtorquespeed | 1100~1600r/min | |
Maxfuelconsumption | ≤193g/kW.h | |
Bore/stroke | 130x126mm | |
MaxMixingCubage(m3) | 7 | |
Fillingrate | 58% | |
Restrate | <=1% | |
Rotationalspeedofthedrum | 0~14(r/min) | |
Slump5cm | about30 | |
Slump8-12cm | about20 | |
Max.Displacement | 420bar/89cc/rev | |
Max.Displacement | 420bar/89cc/rev | |
Deceleratormodel | TOPP68 | |
DeceleratorRatio | 120.3i | |
WaterSupplySystem | Volumeofwatertank | 440 |
WaterSupplyMode | WaterPump; PneumaticPump | |
