Volvo 100m3 Portable Truck Mounted Concrete Pump Truck

Product Description

HB56 Truck-Mounted Concrete Pump is modern construction equipment for pouring concrete consecutively. It has features of good maneuverability, short pparation time, high efficiency, good construction quality, less pollution of the environment. It is widely used in large-scale infrastructure constructions such as bridge, electric power plant, steel works, water disposal plant and high-rise building constructions.

HB56 concretepumpadoptsHinoFSIERV(6X4)threeaxlechassis,excellentpower
performanceandgoodeconomicsFrontXtypeoutriggercouldoperateononeside,andopensemi-outriggerinnarrowarea.5sectionRZtypefoldedboomneedssmallspaceforboomfoldingandunfolding.Themainvehiclepumpingadoptsopeneddeliverytechnology,fullyhydraulicreversingtechnology,intelligentpumpingdampingtechnology,smallpumpingreversingimpact.Theconcretepistoncouldwithdrawautomatically.TheelectricalsystemadoptsPLCcontrolwithcolordisplayscreen,showingtherunningparametersoftheequipment.Theapplicationoftheengineenergysavingtechnologyandtrouble-shootingtechnologyimprovestheeconomics,reliabilityandsafetyoftheconcretepump
Itisthefirst40mconcretepumpwiththreeaxlechassisinChina,andthefirstmachineadoptingXtypeoutrigger,andthefirstconcretepumpadopting5-sectionRZtypefoldedboomfor40-mlevelinChina.





Technical Parameters

Travel
Category	Item	Unit	Parameter
Chassis	Model		FM440
	Manufacturer		VOLVO
	Max.speed	km/h	90
	Max.gradeability		38%
	Min.turningdiameter	m	27.4
	Brakedistance	m	≤10
	Wheelbase	mm	1995+5205+1370+1450
	Tread(front/rear)	mm	2028/1872
	Approachangle/departureangle	.	18/11
	Min.clearance	mm	270
	Tyrespecification		12.00R20
Engine	Model		D13
	Outputpower	kw/(r/min)	324/1400~1800
	Max.torque	N.m/(r/min)	2200/1050~1400
	Displacement	l	12.8
	EmissionStandard		NationIIIGBIII
Others	Dimension(Length×Width×Height)	mm	14885×2500×3990
	Totalvehicleweight	kg	49750
	Fueltankcapacity	l	410
	Fuelconsumptionper100km	l/100km	50
Pumpingoperation
Pumpingsystem	Theoreticaloutput(highpssure/lowpssure)	m3/h		100/163
	Concretepumpingpssure(highpssure/lowpssure)	Mpa		13/8
	Theoreticalpumpingtimes(highpssure/lowpssure)	/min		13/21
	Max.diameterofpumpingconcreteaggregate			40
	Feedingheight			1530
Placingboom	Pumpingslumprange			12-23
	Reachheight			55.7
	Reachdepth			44
	Slewingradius			51.7
	Slewingangle			364
	1stboomstretchangle			96
	2ndboomstretchangle			180
	3rdboomstretchangle			180
	4thboomstretchangle			180
	5thboomstretchangle			260
	Outriggerspan	Overalloutriggerspan		11250±50
		Frontoutriggertransversespan		11400±50
		Rearoutriggertransversespan		11300±50
Others	Dosingtype			Svalve
	Lubricatingmethod			Automaticlubrication
	Controllingmethod			Manual/remotecontrol
	Watertankcapacity			700
	Max.pssureofwaterpump			2
