Detailed Description
Suzhou Top Elevator Parts Co.,Ltd. is amodern manufacturer of lift components, well equipped with advanced machinery capable of producing high quality products including guide system,door system,traction system,safety protection,cabin system,electrical drive system,weight balance system etc.Our company is in possession of advanced production equipment,strong technical force and complete testing equipment,being renowned both home and abroad with first-class production technology,independent intellectual property rights,excellent product quality,reasonable product price and excellent after-sales service.
Drawing of Guide Shoe:
Drawing of Guide Rail:
Dimensions(mm)
| Type | b2 | h3 | h | u | b3 | l1 | l2 | l3 | tastenter |
| Tolerance |
| ±1 | 0
-0.2 | | ±0.5 | ±1.5 | ±0.5 | ±0.3 | |
| TK3 | 72 | 40 | 6 | 3 | 43 | 220 | 90 | 30 | M10 |
| TK5 | 88 | 59 | 10 | 4.5 | 50 | 400 | 180 | 20 | M12 |
| TK3A | 78 | 50 | 12 | 3 | 45 | 200 | 75 | 25 | M10 |
| TK5A | 78 | 50 | 10 | 4 | 45 | 200 | 75 | 25 | M10 |
