FUJIM series dumbwaiter elevator provides swift,convenient and economical vertical transporation for various constructions,which greatly saves the time and human resource,psenting a beautiful environment.
These elevators are widely applied to the hotels,restaurants,apartment buildings,banks,office buildings,hospitals,malls,factories,libraries,labs and post offices,etc. for delivering such items as foods,dishware,daily necessities,money,documents,medicines,cargos,books,instruments and letters,etc.
1. It is of small covering space.It needs no strong construction force.It can always offer the perfect and economical design for both old new buildings.
2. It applies the advanced micro-computer control module to bring about the reliable lift running with the convenient debugging and simple maintenance.
3. Special design brings about the more flexible operation.The car can have multi-layer which is more convenient to display items.
4. Arrival buzzer prompt:When the lift arrives at the designated landing,the announcer prompts the goods pick-up.
5. Window type and push-cart type are available for free door opening design.
6. All the cars and doors apply hairline stainless steel for the bending and making.They are hygiene and beautiful in outer appearance.
Standard decoration
| Capacity(kg) | Speed(m/s) | Car size (CW*CD)mm | Entrance (DW*DH)mm | Hoistway size(mm) | Machine room size | ||||
| Upper and lower straight | (HW*HD) | OH ≥ | PD ≥ | (MW*MD)mm | (MH)mm | ||||
| 100 | 0.4 | 800*800*800 | 800*800 | 1400*1020 | 3600 | 1000 | 1500*1500 | 2500 | |
| 200 | 1000*900*1000 | 1000*1000 | 1600*1120 | 3800 | 1000 | 1600*1500 | 2500 | ||
| 250 | 1000*1000*1000 | 1000*1000 | 1600*1220 | 3800 | 1000 | 1600*1500 | 2500 | ||
| 300 | 1000*1000*1100 | 1000*1100 | 1600*1220 | 3900 | 1100 | 1600*1500 | 2500 | ||
| Function | |||
| Automatic operation | Attendant running | Automatically adjust door opening time | Door re-open at the same floor |
| Arrival charm | Cancel the error command | Parking | |
| Safety Function | |||
| Light curtain protection | Overload device | Inspection Operation | Anti-stall timer protection |
| Fault self-diagnosis | Auto-stop with fault | Repeat open/close door | Up/down over-speed limited protection |
| Device for uncontrolled descending car protection | Device for uncontrolled ascending car protection | Safety circuit protection | Door interlock protection |
| Main contactor protection | Brake detecting protection | ||
| Human-machine interface | |||
| Micro-touch button for car call and hall call | Running state display | No Stop Floor Set | Homing floor set |
| Hoistway Self-learning | |||
| Emergency Function | |||
| Emergency Lighting | Inching running | 5-way intercom | Bell |
| Emergency fire operation | |||
| Energy Saving function | |||
| Fan&Light automatic Off | |||
| Door close time extending | Emergency fire operation | Duplex control function | Opposite door control |
| Sub-C.O.P | IC card control | Automatic Rescue Device | Traction machine monitor |
