Standard function | |||
Travel function | Collective selective control | Collective selective controlling without the psence of operator. | |
Hydraulic drive | We fulfill the elevator travel through controlling the liquid flow in the electronic valve. | ||
VVVF door operator | Motor rotating speed can be pcisely adjusted to get the more gentle and sensitive door machine start/ stop. | ||
Reopen with hall call | In the door closing process, pss reopen with hall call Button can restart the door. | ||
Car stops and door open | The elevator decelerates and levels, the door only opens after the elevator comes to complete stop. | ||
Automatic returning to the base station | When the traffic flow is low, elevator without receiving commanding signals will automatically return to the base floor and standby with the door closed. | ||
Directly running | Under the operator's control, after the direct running button is pssed, the elevator only runs directly according to the directives from inside the car and does not respond to any calls from outside. | ||
Automatic pass without stop | When the car is crowded with the passengers or the load is closed to pset value, the car will automatically pass the calling landing in order to keep maximum travel efficiency. | ||
Safety function | Repeated door closing | If the elevator can not close the door due to certain obstacle or interference, the elevator will reopen or reclose the door until sundries are eliminated. | |
Power on re-leveling | A power failure might cause the elevator to stop between two floors. However, upon recovery of the power, the car automatically moves to the nearest leveling floor. | ||
Overload holding stop | When the car is overload, the buzzer rings and stops the elevator in the same floor. | ||
Startup protection control | If the elevator does not leave door zone with the designated time after it starts, it will stop the operation. | ||
Inspection operation | When the elevator enters into inspection operation, the car travels at inching running. | ||
Up/down over-run and final limit protection | The device can effectively pvent from the elevator's surging to the top or knocking the bottom when it is out of control. It results in more safe and reliable elevator travel. | ||
Down over-speed protection device | When the elevator's down speed is 1.2 times higher than the rated speed, this device will automatically cut off control mains; stop the motor running so as to stop elevator down at over-speed. If the elevator continues to down at over-speed, and the speed is 1.4 times higher than rated speed, safety tongs act to force the elevator stop in order to ensure the safety. | ||
Photocell protection | In the door open and close period, infrared light that covers the whole door height is used to probe the door protection device of both the passengers and objects. | ||
Emergency function | Emergency car lighting | Emergency car lighting automatically activated once power failure. | |
Five way intercom | Communication amid car, car top, elevator machine room, well pit and rescue duty room through walkie-talkie. | ||
Fire emergency return | If you start key switch in main landing or monitor screen, all the callings will be cancelled. The elevator directly and immediately drives to the designated rescue landing and automatically opens the door. | ||
Man-machine interface | Micro-touch button for car call and hall call | New type micro-touch button is used for operation panel command button in the car and landing calling button. | |
Floor and direction indicator inside car | The car shows the elevator floor location and current travel direction. | ||
Floor and direction indicator in hall | The landing shows the elevator floor location and current travel direction. | ||
Energy-saving function | Car ventilation, light automatic shut off | If there is no calling or command signal within the stipulated time, the car fan and lighting will be automatically closed in order to save the energy. | |
Remote shut-off | The elevator can be called to base landing (after finishing the service) through the key and automatically exist the service. | ||
Optional function | |||
Travel function | Operation control at stations | Through turning the key switch installed on a specific floor (optional), the elevator can be arranged to stop service for a certain floors. | |
Door open time extending | Pressing the specialized button in the car5, which can keep the door open for a certain period of time, is convenient for loading and unloading of goods. | ||
Bell | In emergency conditions, if bell button above car operation panel is continuously pssed, electric bell rings on top of the car. | ||
