Detailed Description
Machine Roomless (MRL) Freight Elevator with Steel Plate Floor
Machine Roomless (MRL) Freight Elevator specifications
| Load(kg) | Speed(m/s) | Exterior size of car width x depth x height(mm) | Net door opening width x height(mm) | Shaft size(mm) | Door Open type |
| C.WxC.DxD.H | 2P Central opening | width x depth(mm) | Overhead height | Pit depth |
| 1000 | 0.5 | 1500x1800x2200 | 1200x2100 | 2250x2200 | 4500 | 1500 | Two panel side opening |
| 1.0 | 4500 | 1500 |
| 1.5 | 4600 | 1600 |
| 2.0 | 4800 | 1800 |
| 2000 | 0.5 | 2000x2300x2200 | 1500x2100 | 3150x2660 | 4800 | 1500 | Two panel side opening |
| 1.0 | 5000 | 1500 |
| 1.5 | 5200 | 1600 |
| 2.0 | 5200 | 1800 |
| 3000 | 0.5 | 2470x2560x2200 | 1800x2100 | 3700x3000 | 5000 | 1600 | Four panel center opening |
| 5000 | 0.5 | 2800x3400x2500 | 2400x2400 | 4250x3800 | 6100 | 1600 | Four panel center opening |
