Square Glass Panoramic Elevator for Sightseeing (G101)

This is Square Glass Panoramic Elevator for Sightseeing (G101), observation lift, sightseeing elevator, capsule lift, landscape elevator, geared or gearless, MRL or with small machine room.

Syney observation elevator series are widely used nowadays. In hotels, business places and office buildings, you all can see Syney panoramic elevator silently transporting colorful passengers up and down, adding beautiful sights to buildings. Our lift distincts itself in automatic timing switch and safety device, offering passengers steady moving up and down.

Top and bottom cover	Hairline stainless steel
Ceiling	Flush painted steel, LED light
Cabin wall	Hairline stainless steel
Observation wall	Tempered glass
Handrail	Mirror stainless steel, round tube
Floor	PVC

Elevator	Capacity	Speed	Cabin and Door Decoration
Panoramic Elevator	450kg~1600kg	MR:V≤4.0m/s MRL: V≤2.5m/s	Standard: Cabin: rear wall glass+ stainless steel 3 sides glass + stainless steel Cabin door and main landing door: stainless steel Other landing door: painted steel
			Optional: Four sides glass Mirror stainless steel Etching stainless steel Golden mirror etching finish etc.

Standard functions

No.	Function	No.	Function
1	Collective Selective	24	Door lock stop when running
2	Close door interrupted auto return	25	Level adjust
3	Overload Alarm	26	Auto stop
4	Full load bypass drive	27	Floor signal auto-amend
5	Motor overheat protect	28	Door switch protect
6	Machine room emergency electric operation	29	Anti-slid protect
7	Top floor terminal protect	30	Door switch button
8	Car display	31	Landing door/car door lock at certain period
9	Reset Running	32	Landing door open at psent floor
10	Car emergency lightening	33	Speed feedback
11	Car top inspection	34	Reverse running protect
12	Door close time extending protect	35	Shaft position self study
13	5 part interphone	36	Brake feedback inspection
14	Reverse direction register cancel	37	Standby switch
15	Car Alarm bell	38	Car lightening and fan control
16	Fault register cancel	39	Fault self-diagnosis
17	CPU self protect	40	Running direction signal
18	Auto level	41	Fault history record
19	CAN communication protect	42	Service floor setting
20	Fault auto level	43	Floor display setting
21	Level switch protect	44	Auto return main floor
22	Low speed protect	45	Auto return main floor when fire alarm
23	Shaft self-study diagnosis	46	Contactor feedback detection

Capacity	Speed	Cabin			Shaft size										Max. Rise	Min. floor
DL	V	CW	CD	OP	Standard Shaft		Min. Shaft		Pit depth (mm)		OH (mm)		MRH (mm)		Max R	Min D
(kg)	(m/s)	(mm)	(mm)	(mm)	HW (mm)	HD (mm)	HW (mm)	HD (mm)	STD	Min (No canopy)	STD	Min (No canopy)	STD	Min	(m)	(m)
630 (round)	1	1150	1500	800*2100	2250	2050	2150	2050	2000	1500	4900	4500	2800	STD-200	50	2.7
	1.5						2200	2050	2100	1600	5000	4600			70
	1.75						2200	2050	2200	1700	5100	4700			90
800	1	1150	1800	800*2100	2300	2350	2200	2300	2000	1500	4900	4500	2800		50
	1.5						2250	2350	2100	1600	5000	4600			70
	1.75						2250	2350	2200	1700	5100	4700			90
1000	1	1300	1900	900*2100	2450	2450	2400	2400	2000	1500	4900	4500	2800		50
	1.5						2450	2450	2100	1600	5000	4600			70
	1.75						2450	2450	2200	1700	5100	4700			90
1150	1	1400	2000	900*2100	2400	2550	2300	2500	2000	1500	4900	4500	2800		50
	1.5						2350	2550	2100	1600	5000	4600			70
	1.75						2350	2550	2200	1700	5100	4700			90
1350	1	1500	2100	1000*2100	2650	2650	2550	2600	2000	1500	4900	4500	2800		50
	1.5						2600	2650	2100	1600	5000	4600			70
	1.75						2600	2650	2200	1700	5100	4700			90
1600	1	1500	2500	1100*2100	2700	3100	2600	3050	2000	1500	4900	4500	2800		50
	1.5						2650	3100	2100	1600	5000	4600			70
	1.75						2650	3100	2200	1700	5100	4700			90

Note:
Above standard specification is only for reference. If shaft size at jobsite is different , please contact with us, factory will design suitable one according to your parameter.
