The Extremely Comfortable Travel
A shock-absorbing device is set between the car body and holder to isolate vibration. It superiorly buffers vibration during the elevator running process. It reduces the car vibration and prompts the conformable travel to vast passengers. The combined car wall connection ensures mute effects in the car, the stable and enclosed air pssure.
| Load | Speed | Car Dimension | Hoistway Dimension | Max No. of Stops | Max Travel (m) | Min Span Between Various Floors | Power KW | Distance of Bracket Guide Rail(mm) | |||||
| DL(kg) | V(m/s) | CW (mm) | CD (mm) | OP (mm) | Min HW(mm) | Min HD(mm) | Min S(mm) | Min K(mm) | |||||
| 800 | 2.0 | 1400 | 1350 | 800 | 1900 | 2050 | 1750 | 4700 | 40 | 120 | 2.7 | 13.5 | 2000 |
| 2.5 | 1950 | 4900 | 40 | 130 | 16.8 | ||||||||
| 3.0 | 3600 | 5600 | 35 | 118 | 3.3 | 16.5 | |||||||
| 4.0 | 3800 | 5800 | 50 | 165 | 22.1 | ||||||||
| 1000 | 2.0 | 1600 | 1400 | 900 | 2100 | 2100 | 1750 | 4700 | 40 | 120 | 2.7 | 13.5 | |
| 2.5 | 1950 | 4900 | 40 | 130 | 16.8 | ||||||||
| 3.0 | 3600 | 5600 | 35 | 118 | 3.3 | 19.7 | |||||||
| 4.0 | 3800 | 5800 | 50 | 165 | 26.3 | ||||||||
| 1150 | 2.0 | 2000 | 1350 | 1100 | 2500 | 2100 | 1750 | 4700 | 40 | 120 | 2.7 | 16.9 | |
| 2.5 | 1950 | 4900 | 40 | 130 | 21.3 | ||||||||
| 3.0 | 3600 | 5600 | 35 | 118 | 3.3 | 22.3 | |||||||
| 4.0 | 3800 | 5800 | 50 | 165 | 30.1 | ||||||||
| 1350 | 2.0 | 2000 | 1500 | 1100 | 2500 | 2200 | 1750 | 4700 | 40 | 120 | 2.7 | 18.4 | |
| 2.5 | 1950 | 4900 | 40 | 130 | 23.2 | ||||||||
| 3.0 | 3600 | 5600 | 35 | 118 | 3.3 | 27.2 | |||||||
| 4.0 | 3800 | 5800 | 50 | 165 | 36.2 | ||||||||
| 1600 | 2.0 | 2000 | 1700 | 1100 | 2500 | 2400 | 1750 | 4700 | 40 | 120 | 2.7 | 21.8 | |
| 2.5 | 1950 | 4900 | 40 | 130 | 27.5 | ||||||||
| 3.0 | 3600 | 5600 | 35 | 118 | 3.3 | 33 | |||||||
| 4.0 | 3800 | 5800 | 50 | 165 | 53.3 | ||||||||
