a
bout Sicher Elevator Co., Ltd
Sicher Elevator Co., Ltd. Is a specialized, collectivized transnatio
nal operation enterprise through investment, merger and stock restructuring.
Sicher Elevator Co., Ltd. Covers an area of 147, 600 square meters, with overall floorage a
bout 170, 000 square meters, owns product manufacturing center, R&D center, customer service center, along with elevator testing tower a
bout 108 meters height, 8.0m/s running speed. It also has introduced production facilities and inspecting equipment with advanced world levels from Germany, Italy and other countries, so that keeps a manufacturing capacity a
bout 40, 000 sets as annual output, which is a large-scale and modern manufacturing enterprise, facing the global market from elevators, escalators and parking system equipment
Features:
*Originated from SRH, streamlined handrail system in stainless steel reflects noble style of western Europe with its 180° Arc end and black inlet.
*Advanced co
ntrol system and driving device, superior driving chain, excellent workmanship assures the comfortable operation.
*The safety protection functions as many as 21 items fully comply with natio
nal and European standard.
*The application of VVVF drive(optional)makes escalator(moving walk)be a repsentation energy saving product. By checking the traffic flow timely by means of photo electrical sensor located at the entrance of escalator, achieving auto moving with great energy saved.
*Drive device arranged vertically assures enough space and co
nvenience for maintenance.
| Escalator | GRE20 | GRE30 | Movingwalk | GRM20 | GRM15 |
| Application | Indoor.16-hroperationdaily |
| H(m) | ≤7.2(6) | ≤12 | Horizontalspan | ≤50 | ≤150 |
| Inclination(°) | 30(35) | 30 | Inclination(°) | 10/11/12 | 0-6 |
| Stepwidth(mm) | 600/800/1000 | 1000 | Stepwidth(mm) | 800/1000 |
| Horizontalsteps | 2/23/3(Onlyfor30°) | 3/3 | Upperlandinghorizontaldistance | 400 |
| Speed(m/s) | 0.5 |
| Mainpower | 380V/50Hz/3P |
| Balustrade | Temperedglass(10mm) |
| Handrailbracket | Stainlesssteel |
| Handrail | Black |
| Balustradeheight(mm) | 900 |
| Inner&outerdecking | HairlineSt.St. |
| Skirting | Stainless steel |
| Step | Stainlesssteel |
| Landingplate | Stainlesssteel(anti-sliding) |
| illumination | lightingunderupper&lowerlandingsteps |
| Indicator | Failurecodeindicatoroncontrolcabinet |
| Operation | Emergencystopbutton/Keyswitch/Inspectionoperation |
| Optionalconfiguration |
| Application | Semi-outdoor/outdoor.16-hroperationdaily |
| Handrailbracket | Aluminumprofile |
| Handrail | Green,red,blue,yellow |
| Balustradeheight | 1000mm |
| illumination | Skirtinglighting |
| Comblighting |
| Indicator | Indicatoronouterdecking |
| Directionindicator | Runningdirectionindicatoronouterdecking |
| Step(escalator) | One-piecealuminum |
| Skirting | HairlineSt.St. |
| Landingplate | Aluminumalloy(anti-sliding) |
| Energycontrol | VVVF |
| Lubrication | Automaticlubrication/electriclubrication |
| Externalcladding | HairlineSt.St./Paintedsteel/Glass/Mirrorst.st. |
| |
| Safetydevices | |
| Staticelectricityprotectionofstep | Eliminatestaticelectricityraisedfromrunningofthesteps. |
| Staticelectricityprotectionofhandrail | Eliminatestaticelectricityraisedfromrunningofthehandrail. |
| Emergencystopbuttononentrance | Pushtheemergencystopbuttontostoptheescalator(movingwalk)againstemergencyraise. |
| Handrailentrysafetyprotection | Protectionagainstriskofotherobjectsbeingjammedintohandrailentry. |
| Overspeedprotection | Protectionagainstriskofspeedbeingover20%ofratedspeed. |
| Underspeedprotection | Protectionagainstriskofspeedbeinglessthan20%ofratedspeed. |
| Unintentionalreversalprotection | Protectionagainstriskofunintentionalreversalofthedirectionoftravel. |
| Phasefailureprotection | Protectionagainstriskofphasefailure. |
| Shortcircuitprotection | Protectionagainstriskofshortcircuit. |
| Over-loadprotection | Protectionagainstriskofmotorcontinuallyoverload. |
| Stepsaggingprotection | Protectionagainstriskofstepsbeingbreakageandsagging. |
| Stepsaggingprotection | Protectionagainstriskofstepchainbeingbreakageofundueelongation |
| Stepchainssafetyprotection | Protectionagainstriskofstepchainsbeingbreakageofundueelongation. |
| Combsafetyguard | Protectionagainstriskofforeignobjectsbeingtrappedatthepointwherethestepentersthecomb. |
| Inspectionsocket | Toprovidevoltagetoinspectormaintain. |
| Machineroomguard | Onesafetyplateseparatesmachineroomfrommovablepartssuchassteptoprotectservicepersonnel. |
| Emergencystopbuttononcontrolcabinet | Pushtheemergencystopbuttontostoptheescalator(movingwalk)againstemergencyraisewheninspectionandmaintaining. |
| Handrailspeed-detectionprotection | Whenhandrailspeedis15%lowerthanthestepspeed,itstopsin15seconds. |
| Brakeover-distanceprotection | Whenstepbrakedistanceis1.2timeslargerthanthestipulateddistance,itpventsitfromstartagain. |
| Skirtingguard | Protectionagainstriskofforeignobjectsbeingjammedintoclearancebetweenstepsandskirting. |
| Flooranti-startprotection | Itstopswhenthefloorplateisremovedoropened. |
| Maindrivechainssafetyprotection | Protectionagainstriskofdrivechainsbeingbreakageorundueelongation. |
| Skirtingbrush | Brushesonskirtingtoenhancethepassenger'ssafety. |
| Hostbrakedetection | Whenitdetectsthereleaseconditionofthehostbrake,itpventsitfromstartbeforeitsrelease |
| Anti-crawldevice | Itpventsthepassengersfromcrawlingtoexternalhandrail |
| Anti-skiddevice | Itinstallsoutercoverplatewhichisclosedtohandrailheight.Itpventsthepassengersfromaccidentalcrawl,skid,fall. |
| Arrester | Itpventsthepassengersfromenteringintotheareabetweenwallandhandrail,betweentwoescalators(movingwalks) |
| Protectionbaffle | Protectionbaffleissetinthecrossingofouterhandrailedgeandanyobstacle. |
| Auxiliarybrake | Auxiliarybrakewillactandstoptheescalator(movingwalk)incaseofmaindrivechainsbreakageorthestepsorhandrailchangingfrompsentdirectionofmotion. |
