Designing and Styles mingled with mordern atmosphereWith Incorporation of the well-developed escalator technology, advanced micro-computer co
ntrol system, high strength truss structure, classical driving system and completed safety dvices. IE20 series of escalator full ensure our products safe, reliable, endurable and bring steady and comfortable riding. Complying with European standard EN115, our escalator are applicable for heavy passenger flow location such as market, supermarket, hotel , subway, airport and railway station etc.
-- Streamlined handrail system in stainless steel refelcts noble sytle of western Europe with its 180 degree arc end and black inlet.
-- Advanced co
ntrol system and driving device, superior driving chain, excellent workmanship assures the safe, reliable and satable operation.
-- The safety protection functions as many as 21 items fully comply with natio
nal and European standard.
-- Automatic lubrication system lubricates all kinds of driving compo
nents which prolo
ngs products' operation life greatly.
-- The application of VVVF drive (optional) marks escalator be a repsentation energy saving product. By checking the traffic flow timely by means of photo electrical sensor located at the entrance of escalator, achieving auto moving with great energy saved.
-- Micro-computer co
ntrolled system performs with rapid calculation speed, high reliable moving, and also with failure code fixed, easy to be maintained.
-- Drive device arranged vertically assures enough space and co
nvinience for maintenance.
IE20 Escalator Standard specification| Application | Indoor, outdoor, 16-Hr operation daily |
| Rise (m) | <= 6 | <=7.5 |
| Inclination (degree) | 35 | 30 |
| step width (mm) | 600/800/1000 |
| Horizontal steps | 2/2 | 2/2 or 3/3 |
| speed ( m/s) | 0.5 |
| main power | 380V/50Hz/3P |
| balustrade | tempered glass (10mm) |
| handrail bracket | stainless steel |
| handrail color | black |
| balustrade height | 900 mm |
| innter & outer decking | hairline stainless steel |
| skirting | hairline stainless steel |
| step | stainless steel / aluminum alloy |
| landing plate | Anti sliding stainless steel |
| illumination | lighting under upper/lower landing steps |
| Indicator | failure code indicator on control cabinet |
| Operation | emergency stop button, key switch, inspection operation |
