Marine Ship Solas 5.9m Free Fall Lifeboat Manufacturers

1. Marine totally enclosed lifeboat and free fall life boat

2.Boat body material: fire-ptended type FRP.

3.Fitted with release mechanism and free falls in to the water.

4.t can self-righting by itself when capsized.

5.Equipments is equipped according to SOLAS requirement.

6.The surface for walking is the antiskid.

7.Equip a manual pump remove the pending in the boat.

8.Running time of rescue boat when full-loaded & full-speed is more than 24 hours.

9.Speed(full load):>6knots

10.All seats are according to requirement of cosmetology, four point safe belt and cushion were fitted on seat,

11.Door was fitted at lifeboat stern, Natural ventilation is achieved via an automatic valve located on the front of superstructure. The valve will be above water in al heeling conditions (0-180 degrees).The valve also pvents the cabin from becoming dangerously under-pssured while the engine is running.

12.A water spray system is installed for fire protection. The spray system consists of an engine driven pump, which takes seawater from the lowest possible location under the boat ensuring that no flammable liquid is drawn into the system. The spray system provides water over the entire surface of the craft (tanker version only)

13.The compssed air system installed has a sufficient capacity to provide air for the maximum number of personnel and engine combustion for a minimum of 10 minutes. Toxic fumes or gas pvention have been made to recharge the air system from the ship's compssed air system(tanker version only).

Free Fall Lifeboat:

Product Name	Totally Enclosed Common Lifeboat
Dimension	Capacity	Hook Distance	Engine	Total Weight
5.00M*2.20M*1.10M	26	4.6M	380-J	4610KGS
6.50M*2.32M*1.15M	36	6.1M	380-J	5920KGS
7.50M*2.78M*1.15M	58	7.0M	380-J	7861KGS
8.50M*3.20M*1.25M	85	8.1M	380-J	11667.5KGS
11.70M*3.70M*1.25M	150	11.1M	N485-J	20332KGS

Model	Dimension	Capacity	Hook Distance	Engine	Total Weight
NM50F	5.00M*2.20M*1.10M	26	4.6M	380-J	4610KGS
JYB57F/C*	5.80M*2.32M*1.15M	33	5.3M	380-J	4602 / 4260 KGS
NM65F	6.50M*2.32M*1.15M	36	6.1M	380-J	5920KGS
NM75F	7.50M*2.78M*1.15M	60	7.0M	380-J	7861KGS
JYB80F/C*	8.10M*2.96M*1.20M	65	7.6M	380-J	9137.5 / 8787KGS
NM85F	8.50M*3.20M*1.25M	85	8.1M	380-J	11667.5KGS
JYB99F/C*	10.07M*3.80M*1.25M	120	9.4M	N485-J	16400 / 159507KGS
NM1170F	11.70M*3.70M*1.25M	150	11.1M	N485-J	20332KGS

Life boat davit:

Our Advantage of totally enclosed free fall lifeboat :

1.Professional is our guarantee

Specialized designers, engineers and technical staffs sever for the manufacture.

Marine class certificates of ABS, BV, CCS, DNV, EC, GL, KR, LR, NK, RINA, RS are available.

2.Designs change for you

Our design can meet your unique specifications or special requirement.

3.World-wide Service system

Just yours a telephone or an E-email, we can know your demand in the shortest time. Our specialized engineersand technical personal will reply and satisfy your request soonest and rapidly provide technical explanation, all kinds of spare parts and accessories.

4.Outstanding quality, strict quality control, reasonable cost, facilitates maintenance

A strict quality control is utilized throughout the whole process of the manufacturing.

5. Quality and client's satisfaction is our pursue/

We pursue win-win cooperation and hope to get your attention.

Factory:



Product Range:We are specialized inall marine equipments and technique solution, that means we could offer you all marine equipments and accessories.

Product Design:We have bigstrong engineer team, for all marine products, we will design drawings according to ur requirements, or check the drawings you give us, all productions must be start after drawings/confirm/iation.

Product Process:all produt flow are finished in our manufacture bases, so thequality and delivery time

could keep the same good, alsoavoid some details mistake.

Product Inspection:We haveISO certificate, and general products, we will provideMill Certificate, also, we

could provideABS, BV, CCS, DNV, GL, LR, KR, NK, RINA, RS certificate, and we acceptthird party inspection, such as SGS etc. our clients also could come tovisit our factor.
