| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power | 5KW DC |
| Controller | Curtis brand, Series excited, imported |
| Passenger capacity | 2 |
| Range (loaded) based on flat road at aspeed of 20km/h (km) | > 55 |
| Max.Speed(km/h) | 40 |
| Minimum turning radius (m) | 5.3 |
| Max.Climbing ability | 20% |
| Max.Loading weight | 1500kgs |
| Overall dimensions (mm) | 4730x1500X2100 |
| Cargo bed dimensions (mm) | 3000x1500X550 |
| Body and frame | |
| frame | Welded steel framework with sand blasting+paint treatment |
| Body | FRP body |
| Roof | FRP body |
| Cabin | Aluminum frame +glass door |
| Windshield | Laminated glass |
| Large Seats: | With backrest and headrest, sliding |
| Floor | Anti-sliding ruber floor mat |
| Battery sliding system | |
| Side rear view mirror | |
| Electric system | |
| Lighting system and horn | 2 combined front lights(headlight, turning light, position light), 2front foglight, 2taillight(turn signals and brake lights), with DC-DC converter (converting from 48V to 12V), horn. |
| Dashboard meter | Voltameter, ammeter, odometer, emergency switch;Combined switch, meter indicator |
| Audio System | Radio and MP3 adaptor, with 2speakers |
| Wiper | 12V, 50W, single arm |
| Charger | Input 110V-240V~50Hz-60Hz, output 48V, 25A |
| Steering and Suspension | |
| Steering system | Recirculating ball steering gear+ steering wheel |
| Brake system | Four wheel hydraulic drum brake+ parking brake |
| Brake assistant | Vaccum pump assistant |
| Transmission system | Clutch, gear box, transimmison shaft |
| Front Suspension system | Plate spring +hydraulic shock absorber |
| Rear Suspension system | Integrated rear end, rear plate spring +hydrualic shock absorber |
| Wheel &Tyre | 185R14C tubeless tire, 14*5.5 Jsteel rim |
| Color | |
| Body Color | 4 standard color:Pearl white/industrial yellow/pearl red/saffron yellow |
| Seat Color | White and Tan |
| Others | |
| Provides various options like:Heater, seatbelt, EPS, etc... |
