| Overall Length (mm) | 7510-8310 |
| Overall Width (mm) | 2490-2500 |
| Overall Height (mm) | 2990-3050 |
| Rated Mass (Kg) | 8040-9470 |
| Max.Loading Mass(Kg) | 2090-3155 |
| Max. Speed(Km/H) | 90 |
| Model | Cummins/Yuchai |
| Manufacturer | Cummins/Yuchai |
| Power (HP/KW) | 160-210 |
| Fuel Consumption(100Km/L) | 23.9-26.8 |
| Fuel | Diesel oil |
| Exhaust Standard | Euro 3/4/5 |
| Manufacturer | JAC/ISUZU/Dongfeng/Foton/FAW |
| Steering | Integral hydraulic power steering |
| Fuel tank | 240L |
| Tyre | 9.00-20/9.00R20 |
| Front/Rear Overhang (mm) | 1335-1400/2210-2535 |
| Wheel base (mm) | 3800/3900 |
| Wheel Track(mm) | 1880/1860 |
| Valve Manufacturer | ShinMaywa (Japan) |
| Tank Capacity(m3) | 8-10(5T) |
| PLC | imported |
| Tipper Device | Option-Hanging barrel type (240L/660L/1100L) and shovel board |
Note: We can supply different kinds of garbage trucks,water trucks,swppers and customized upper units with desgin requiements in especial.Our truck chassis brands are from JAC,Dongfeng,HOWO,HINO,ISUZU,FOTON(top 1 level in China market)
We,JiangsuYuedaSpecialVehicleCo.,Ltd.WhoisoneofthebiggestmanufacturerofcompssiongarbagetrucksinChina,andalso2008BeijingOlympic,Paralympic Games,2010ShanghaiWorldExpo.,2016HangzhouG20Summitdesignated
environmentalsanitationvehiclesupplier.Andwe also supplyagriculture machines,bus,UAV(unmanned aerial vehicle),
YuedaVehicleisabranchvehicleindustryofYuedaGroup(ChinaTop130,ownsfamousbrandsincludingKIA car,
Mahindra Jinma tractor,Aunde textile,Carrefour supermarket,Costa coffee,Triumph bra,Diaverum health system), cooperateswithFujiHeavyIndustries(WorldTop500),introducedthemostadvancedtechnologyfromit.
Yueda Vehicle has 3 serials, more than 50 models, the main products are compssion garbage truck(rear & side mounted), garbage transit trucks, road cleaning trucks, water trucks, high-pssure washing trucks, food waste garbage trucks, garbage stations, and so on.
ThetotalinvestmentofYuedavehicleisRMB356million,coversanareaofnearly200,000squaremeters,152acresofland
planning,spareplant135acres,thetotalinvestmentisRMB180millionforfirstphaseproject.
