Basic Information | ||||
Outline size(L×W×H)(mm) | 7500*2300*2650 | Cargo inline size(L×W×H)(mm): | / | |
Rating mass(kg) | / | Empty mass(Kg): | 5180 | |
Full mass(kg) | 9400 | Emission standard | Euro 3 | |
Engine Information | ||||
Power/displacement(KW/ML) | 120HP | Type | Diesel engine | |
Chassis Information | ||||
Wheelbase(mm): | 3800 | Axle load(kg) F/R | 3565/5865 | |
Tire | 8.25-16 | Max speed (km/h): | 95 | |
Front suspension(mm) | 1210 | Rear suspension(mm) | 1805 | |
Front track(mm) | 1770 | Rear track(mm) | 1680 | |
Approach angel(°) | 24 | Departure angle(°) | 14 | |
Steering | Power steering | Brake | Air brake | |
| control system | manual or automatic | |||
Configuration | 1,Optional 120L ,240L(single box,Double barrel)Or 360L,660L,garbage binlifting tilting mechanism, You can also choose other types of ground hopper loading mechanism. 2,There are two sets of manual and automatic control Method, the operator can control the cabin or in the middle of the back side Truck, very convenient and effective. 3,Emergency braking device stops working button. 4,Garbage body with a frame design, elegant appearance, solid structure, Large effective capacity. 5,With a special collection box, sewage Direct access during compssion cesspool that Effectively pvent secondary pollution caused by sewage leaks. 6,Hydraulic system design, realization truck Bi garbage compssion function, which is to improve the compssion The compssion ratio up to 1: 2.5, the garbage can reach more than 600~800 kg/Compssed cubic meters. | |||
Quote Lifetime | 30workdays (we promise the quote is effective in the lifetime!) | |||
