Electric system | controller | 1268/400A | ||
battery | trojan battery 8V 6 units | |||
motor | KDS48V/3.7KW motor | |||
charger | Computer Intelligent input 220V/110V ourput 48V 20A | |||
Charging time | Less than 12 hours discharging rate 80% | |||
Body configuration | Glass | PC glass | Sun Roof | ABS Vacuum forming |
seat | leather | Floor | Autiskid rubber floor | |
Rear mirror | Handoperated, both side | Steering | Dual automotive-style strut and self-adjust rack-and pinion steering | |
DC/Light/Signal | 48V/12V-300W Front light turning light rear light horn Buzzer | |||
Body | PP Vacuum forming | |||
Dash Board | PP Vacuum forming Voltage Indicator 48V Switch Head Lights Switch - Indicators Right/Left key switch Switch - Forward/Reverse | |||
Braking system | Rear drum brake+compound pedal brake | |||
Front axle and suspension | Independent suspension helical spring +cylinder hydraulic shock absorption | |||
Rear axle and suspension | Integral type transaxle, gear ratio 12.31: 1, semi-independent transaxle, spring, cylinder hydraulic shock absorption | |||
Tire diameter | 452mm | |||
Parameter | Length*width*height | 3600*1200*1900mm | ||
Container sixe | 1840*1086*265mm | |||
Loading passenger | 2 | |||
Max speed km/h | 22km/h | |||
Mileage /km | 70_ 90km flat road | |||
Container truck KG | 300KG | |||
Max climbing ability | 25% | |||
Mini turning radium m | 5.4m | |||
Mini ground clearance | 110mm | |||
Wheel base | Front 930/back 1010mm | |||
Braking distance | 5.5m | |||
