| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power | 5.3KW DC /5KW AC |
| Controller | Curtis brand, imported |
| Passenger capacity | 2 |
| Range (loaded) based on flat road at aspeed of 20km/h (km) | >80-100 depends on DC and AC system |
| Max.Speed (km/h) | 40 |
| Minimum turning radius (m) | 4.5 |
| Max.Climbing ability | 20% |
| Max.Loading weight | 450kgs |
| Overall dimensions (mm) | 3420*1290*2060 |
| Body and frame | |
| frame | Welded steel framework with phosphate+electro-coating treatment |
| Body | PP plastic front body +PP plastic rear body |
| Roof | Fibreglass |
| Windshield | One-piece Laminated glass |
| Large Seats: | Rebond seat +artificial leather, formed armrest, plastic seat bottom |
| Floor | Rubber |
| Dashboard in black plastic | Forward/reverse switch, battery capacity indicator, ignition key |
| Rear cargo box | Manual lifted steel box |
| Beverage holders | 4 cups drink holders |
| Electric system | |
| Lighting system and horn | 2 headlights, 2front turn signals, 2taillights( each combined 1brake light with 1turn signal), with DC-DC converter (converting from 48V to 12V), horn.Reversing alarm |
| Meter | Speed, mileage, headlight indicator, emergency light indicator, turn signal indicator, reverse indicator |
| Charger | Input 110V-240V~50Hz-60Hz, output 36V/48V, 20A/25A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | Four wheel hydraulic brake, front disc, rear drum brake, with parking brake |
| Accelerator | Stepless speed change |
| Suspension system | Front and rear plate spring +cylinder hydraulic shock absorber ,Rear Integrated Axle |
| Driving mode | Rear axle two stage deceleration, motor direct driving |
| Rear axle | Integrated |
| Wheel &Tyre | 10x6 Alumimum wheel &205/50-10 4PR |
| Color | |
| Body Color | 6 standard color:Pure white/Pure Black/Champagne/Red/Navy Blue/metallic Green |
| Seat Color | 2 standard color:White and tan |
| Others | |
| Provides various options like:Wood finish dashboard/backrest cover/steering wheel, onboard charger. |
