Main Technical Parameter | ||||
Product Name | SHACMAN Bulk Power Goods Tanker | Overall Dimension(mm) | 12000×2500×3990 | |
Curb Weight (kg) | Approx * 16805 | Tank dimension (L*Diameter)(mm) | 8650×2500 | |
Wheelbase (mm) | 1800+4500+1350 | Number of Axles | 4 | |
F/R Suspension(mm) | 1525/2825 | Appr/Dep Angle(º) | 18/12 | |
Steering Type | LHD(Power steering) | Max Speed(km/h) | 101 | |
Cab Allowed Persons | 3 | Cab type | Flat proof, single sleeper, air conditioning | |
Chassis Technical Parameter | ||||
Chassis Model | sx1315 | Chassis Manufacturer | Shanxi Automobile Group Co., Ltd | |
Gear Box | FAST10 speed forward and 1 reverse | Transmission type | Manual | |
Drive Type | 8*4 | Brake System | Air brake | |
Leaf Spring No. | 11/11/-,4/4/12,11/11/12 | Front/Rear alxe load(kg) | 9000/16000 | |
Tire Spec. | 12.00R20 | Number of tire | 12with a spare | |
Engine Technical Parameter | ||||
Engine Model | WP10.336 | Engine Brand | Weichai | |
Fuel Type | Diesel | Emission Standard | Euro 3 | |
Displacement ( ml ) | 9726 | Power (KW) | 247(336hp) | |
Superstructure Parameter | ||||
1.Working pssure is 2Mpa, discharging speed is 1-1.3t/min, Under certain condition, material discharging height can be or less than 25 m. | ||||
2.Remaining powder rate:≤1%, Vertical conveying height(m)>15m Horizontal conveying distance (m)>5m | ||||
3.Tank material: 6mm good quality carbon steel Q235 | ||||
4. Equipped with one 10 m3 air compssor | ||||
Warranty | One year from the date of supply | |||
Condition: | New | Storage: | bulk powder | Drive Wheel: | 8x4 |
Horsepower: | 251 - 350hp | Transmission Type: | Manual | Fuel Type: | Diesel |
Tank Volume: | > 30000L | Engine Capacity: | 9726 | Dimensions (L x W x H) (mm): | 12000*2500*3990 |
Brand Name: | HOWO-CLW | Place of Origin: | Hubei, China (Mainland) | Model Number: | ZZ1317 |
Gross Vehicle Weight: | 40000 | color: | black cab and white supstructure(optional) |
Packaging Details: | whole vehicle in nude or wax , spares in waterproof kit, and on RO-RO or bulk ship, etc |
| Delivery Detail: | about 35 days after receiving down payment |
