Half Height Roof Cab, tilt cab | Drive mode | ZZ4257M3231W |
| Model | 6×4 | |
Engine | Model | Sinotruk Engine |
| Displacement(cc) | 9726 | |
| Max output power(Hp/rpm) | 260HP | |
| Max torque(N.m/rpm) | 1460/1450 | |
Transmission | Model | 12JS160 |
| gear ratio | I, 12.65II, 8.38 III, 6.22 IV, 4.57 V, 3.40 VI, 2.46 VII, 1.83 VIII, 1.34 IX1.00R, 13.22 | |
| Gear positon | 8 6 4 2 L 7 5 3 1 R | |
Clutch | Mode | Single plate,dry,screw spring |
Rear Axle | Model | Steyr Technology(4.8,5.73), 16 ton payload |
Main parameter | Overall Dimension(mm) | 6095*2495* 3490 |
| Rear cargo dimension(mm) | 5660×2350×1500 | |
| Wheel base(mm) | 4350+1350 | |
| Tread(mm) | 2040/1860 | |
| Suspension arm(mm) | 1495/1005 | |
| Curb weight(Kg) | 13350-14400 | |
| Rated payload(Kg) | 200000 | |
| GVW(Kg) | 40000-42900 | |
| Max speed (Km/h) | 80 | |
| Radius of turning(m) | 10 | |
| Tire | 12.00-22.5 | |
| Steering system | Dual-circuit brake,WABCO SYSTEM WITH ABS | |
Brake system | Mode | Dual-circuit brake,WABCO SYTEM |
| Brake slack adjust | Automatic adjust | |
| Other | conditioner | Optional |
| Electric glass | Optional |
