Water-Tank Truck

Water tank truck

Detailed Product Description

Water tank specification:

Volume: 4CBM, 6CBM, 8CBM, 12CBM, 16CBM, 19CBM, 25CBM, 30CBM

Pump: Pump in and Pump out(Optional)

Middle duty truck chassis

Drive: 4*2/6*2
Cab Seating Capacity(includes driver): 2 persons with Half height roof cabin
Overall Dimensions(L*W*H/mm): 8780/8980/10990* 2495* 3330/3900
Cargo box(mm): 6460/6130/8500/9500*2300*550/800/

Engine:
1. Displacement: 5900CC/6557CC/6494CC/7127CC
CA6DF2D-19 190HP
YC6J190-20 190HP
EQB210-20 210HP
CA6DF2-22 220HP
CA6110/125Z1A1 180HP
YC6J180-21 180HP
CA6DF2D-16 160HP

Transmission:
1.
CA6T138-85
6J80T
CA6T123-62
6J70T
6J80T
CA6T18-85

Curb Weight(kg): 7400/8900
Max Load Capacity(kg): 12000/13000
Gross Vehicle Weight(kg): 19400/21900
Max Speed(km/h): 90
Tire: 9.00-20, 9.00R20, 10.00-20, 10.00R20

Heavy duty truck chassis:

HFC3201KR1/HFC3251KR1/HFC3255K1R1/HFC3253KR1/HFC3254K2R1
Drive: 6*4 / 8*4
Cab Seating Capacity(includes driver): 2 persons with Half height roof cabin
Overall Dimensions(L*W*H/mm): 8265/8960/9395* 2495/2560* 3330/3500
Cargo box(mm): 5400/5600/5660*2300*1350/1500
(T, F AND FRONT MODEL LIFTING SYTEM OPTIONAL)

Engine:
1. Chinese engine Displacement: 9726CC/9839CC
WD615.56 260HP
YC6M280-20 280HP
WD615.50 290HP
WD615.31 310HP
YC6M320-20 320HP
WD615.46 360HP
2. American CUMMINS Displacement: 10800CC
ISM380E 20 380HP
ISM440E 20 440HP
Transmission:
1. Chinese
RT-11509C+QH50
9JS150T-B+QH50
2. German
ZF16S 1650
ZF16S 1950
ZF16S 221

Curb Weight(kg): 13350-14400
Max Load Capacity(kg): 26420-28500
Gross Vehicle Weight(kg): 40000-42900
Max Speed(km/h): 80
Tire: 11.00-20, 11.00R20, 12.00-20 12.00R20 12.00R22.5
