| Item | Description |
| Controller | Curtis controller, 400A, imported from USA directly |
| Motor | Rated power 6.3KW(8.6HP)DC or 10KW (13.6HP) AC motor,Chinese brand |
| Battery | Trojan battery, 2 groups, 24xT105+, imported from USA directly |
| Charger | Two 72VSmart transformed Charger(input 110V-240V, 50-60HZ, output 72V/25A) |
Performance
| Item | Description |
| Passenger Capacity | 23 (15 seats facing forward, 8seats facing backward) |
Range (loaded) (km)* | up to 70 |
| Max.speed (km/h) | up to 45 |
| Min.turning radius (m) | 6.5 |
| Max.climbing ability(loaded) | up to 20% |
| Max. movement after brake at speed of 20km/h | ≤7m |
| Max.loading weight (kgs) | 1840 |
| Charging time (hour) | 8-10 |
| Battery lifespan (cycles) | 750 |
Dimensions
| Item | Description |
| Overall dimensions (mm) | 5950x1950x2170 (LxWxH) |
| Min.ground clearance (mm) | 165 |
| Wheelbase (mm) | 3200 |
| Front wheel tread (mm) | 1692 |
| Rear wheel tread (mm) | 1700 |
Body and frame
| Item | Description |
| frame & Chassis | Welded steel framework with sand blasting and painting |
| Body | Fibreglass |
| Roof | FRP with aluminum frame, two layers, with roof handle |
| Windshield | Laminated glass with wiper |
| Roof supports | Steel, painted in grey color |
| Seat | Reborn sponge with artificial leather |
| Armrest | Steel tube |
| Floor | Bamboo floor with Skidproof leather |
| Beverage holders | 1 cups holders |
| Side rear view mirror | 2pcs, one long-arm mirror and one small mirror |
Electric System
| Item | Description |
| Lights | 12V, headlight (H/L beam), front turning light, front fog light Rear taillight (brake light and rear turing light) and reverse light |
| Horn | Electric horn, 12V |
| Reverse buzzer | Electric, 12V |
| Combination switch | |
| DC/DC converter | 472V/12V |
| Digital Meter | with Current meter, voltometer, speedometer and various indicators |
| Audio system | Radio with MP3 receiver and 2 waterproof speaker |
Steering & suspersion
| Item | Description |
| Steering System | Single-stage rack and pinion steering system, automatic rocker compensating function, with hydraulic power assistant steering system |
| Brake System | 4-wheel hydraulic front disc rear drum brake with vacuum booster, with hand park brake |
| Accelerator | Resistance type, stepless speed change |
| Front suspension | Independent suspension |
| Rear suspension | integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Transmission system | Clutch, 5F+1R gear box, transmission shaft |
| Wheel & Tyre | 215/70R15C 8PR tyre, with steel rim |
Option Accessories
To increase the sales value of our vehicles, we also provide many optional accessories.
| Item | Option description |
| 1 | 2-point seatbelt |
| 2 | Overshadowing Curtain |
| 3 | Battery watering pipe |
| 4 | Water pump (handle) |
| 5 | Aluminum rim |
