Detailed Description
Changan Bus is the state-own professio
nal leading bus manufacturer in China.We have produced buses over 40 years.
There are over 5,800 buses running in many countries including Asia, Africa, Latin America and some other areas.
Our buses are from 5.5m to 11m length, 15-77 seat capacity.They are suitable for city bus, passenger bus, school bus, commuter/labor bus, cargo van, and so on.
11 mlabour bus SC6108
GCC, CCC and ISO9001
Can be designed LHD or RHD
2 doors is possible
Emergency door is visual
| Item | SC6108 |
Dimension
| Length× width× height(mm) | 11000*2490*3010 |
| Overhang F(mm) | 2160 |
| Overhang R(mm) | 3240 |
| Wheelbase (mm) | 5500 |
| Weight | Total mass (kg) | 14500 |
| Performance | Min. Vehicle turning circle (m) | 9 |
| Min. Ground clearance | 248 |
| Max. Speed (km/h) | 100 |
| Angle (app/dep) (0 ) | 10/10 |
| Seat capacity | 71 |
| framework | Straight beam |
| Engine | Model | EQB180-20/132KW |
| Type | 6 cylinder in-line |
| Rated-power (kw/r/min) | 132kw |
| Max. Torque (N. m) | 610/1600 |
| Displacement (L) | 6 |
| Bore ×stroke (mm) | 102× 120 |
| Emission standard | Euro II |
| Fuel type | Diesel |
| Clutch | Type | Diaphragm |
| Size | 380 diameter |
| Clutch boost | With 900 pump |
| Transmission | Model | QJ705 |
| Max. torque | 750 |
| Shifts | 5+1 |
| Control systems | Flexible shaft |
| Front axle | 5T |
| Rear axle | 9T |
| Braking system | Steering | Power steering |
| Service brake | Dual-circuit air braking system |
| Parking brake | Air-cut brake |
| F/R braking dia. | 400 diameter |
| F/R braking shoe with | 130/220 (1630/2620) |
| Radiator | Cuprum |
| Suspension style | Steel leaf spring |
| Tyre | 10.00-20 |
| Oil tank capacity | 256L |
| Generator | 70A |
Co
ntact us for more details:Tel:+86-312-2354337 /2354365 /2354485 /2354253
Add: Changan Industry Park, Dingzhou City, Hebei, China
Post code: 073000
Worldwide Agents /Distributors /Wholesalers wanted! Product Image
