| Battery | Deep cycle, lead acid battery, Trojan brand, imported |
| Motor Power | 5KW DC, 7KW AC, 7.5KW AC |
| Controller | Curtis brand, Separated/Series excited, imported |
| Passenger capacity | 14 |
| Range (loaded) based on flat road at aspeed of 20km/h (km) | >50, 65, 75 depending on different configuration |
| Max.Speed(km/h) | 45 |
| Minimum turning radius (m) | 5.35 |
| Max.Climbing ability | 20% |
| Max.Lifting weight | 1120kgs |
| Overall dimensions (mm) | 5000x1490x2050 |
| Ground Clearance (mm) | 135 |
| Body and frame | |
| frame | Welded steel framework with sand blasting+paint treatment |
| Body | FRP |
| Hard door | Steel frame+laminated FRP sheet cover |
| Front Windshield | Laminated glass |
| Side window | Safety glass |
| Large Seats: | Sponge +artificial leather, aluminum armrest |
| Floor | Bamboo board+ rubber |
| Electric system | |
| Lighting system and horn | Front:2 Headlights (High beam and dipped headlight), 2front turn signals, 2fog lights;Back:2 rear turn signals, 2taillights(position light &brake light), 1fog light, 1reverse light),with DC-DC converter (converting from 48V to 12V) ,horn. |
| Dashboard meter | Current meter,voltage meter, speedometer |
| Charger | Input 110V-240V~50Hz-60Hz, output 72V/48V, 25A |
| Steering and Suspension | |
| Steering system | Single-stage rack and pinion steering system, automatic rocker compensating function |
| Brake system | 4-wheel hydraulic brake +hand brake |
| Transmission system | Clutch, 4F+1R gear box, transmission shaft |
| Front Suspension system | Independent suspension, cylinder hydraulic vibration absorber |
| Rear Suspension system | Integrated rear end, steel plate spring suspension, cylinder hydraulic vibration absorber |
| Wheel &Tyre | 4J*12 steel rim, 155R12,8PR tyre, with wheel cover |
| Color | |
| Body Color | Pure white/Pure Black /Pearl Red/Sapphire Blue/Greece Yellow/Lake Green |
| Seat Color | White and Tan |
| Others | |
| Provides various options like:Seatbelt, solar panel, enclosure, Overshadowing Curtain, aluminum rim, CD player, etc.. |
