| Chasis Model | ZZ1257M4647C |
| Truck Brand | SINOTRUK-HOWO |
| Dimension(Lx WxH)(unloaded)(mm) | 10350×2496×3048 |
| Tank Volume(m3) | 20m3(Optional: 10m3, 15m3,18,25m3) |
| Tank body(thickness):5mm,material:carbon steel; sprinkling equipment both in front and in rear; special anti-corrosion treatment |
| Approaching angle/Departure angle(°) | 16/12 |
| Overhang(front/rear) (mm) | 1500/2900 |
| Wheel base (mm) | 4600+1350 |
| Max speed(km/h) | 75 |
| Curb weight(kg) | 11360 |
| Total Weight(kg) | 25000 |
| Engine | Model | WD615.97C,water-cooled,four strokes,6 cylinders in line with water cooling,turbocharged and inter-cooling, directly injection |
| (Steyr technology, made in China) | Fuel type | Diesel |
| Power, max(kw/rpm) | 300HP(266hp,290hp,336hp,371hp for option) |
| Emission | EURO III(Optional: EUR II, EUR IV,EUR IV) |
| Fuel tanker capacity (L) | 350 |
| Transmission | Model | HW19710CL,10 forward&2 reverse |
| Brake system | Service brake | Dual circuit compssed air brake |
| Parking brake | spring energy, compssed air operating on rear wheels |
| Steering system | Model | ZF8098 |
| Front axle | HR7 |
| Rear axle | MCY13Q |
| Tyre | 295/80R22.5 |
| Electrical system | Battery | 2X12V/165Ah |
| Alternator | 28V-1500kw |
| Starter | 7.5Kw/24V |
| Cab | HOWO76 standard cab, one sleeper with air-conditioner ,all-steel forward control,55ºhydraulically tiltable to the front,2- arm windscreen wiper system with three speeds, laminated windscreen with casted-in radio aerial, hydraulically damped adjustable driver's seat and rigid adjustable co-driver's seat, with heating and ventilating system, outer sun visor, adjustable roof flap, with stereo radio/cassette recorder, safety belts and adjustable steering wheel, air horn, with 4-point support fully floating suspension and shock absorbers
HW79 Cab with two berth for optional |
